seca 264 Digital Stationary Stadiometer with Wireless Transmission is a wall-mounted digital height measuring device for clinical and professional use. The heel positioner and the seca Frankfurt Line on the headpiece help position the patient correctly to support consistent, accurate measurements. Height values are shown on a white backlit display on the headpiece for easy reading at eye level.
The seca 264 can transmit measurement data wirelessly to compatible seca 360° wireless printers, wireless scales, or a PC, which can help integrate height values into documentation and workflows. Battery operation and wall-mounting capability make the unit suitable for exam rooms, outpatient clinics, and other care settings where a fixed stadiometer is preferred.
Features and benefits
- Wall-mounted digital stadiometer for standing height measurement
- Heel positioner and seca Frankfurt Line to support correct patient posture
- White backlit display on the headpiece for direct reading
- Wireless data transmission to seca 360° wireless printer, wireless scale, or PC
- Battery-powered operation without a permanent power connection
- Functions include hold, auto-print, automatic calibration, and automatic switch-off
- Supports cm/inch switch-over and user-defined zero setting
- Acoustic signals and backlighting can be activated as needed
Technical data
- Measuring range (cm): 30 to 220 cm
- Measuring range (inch): 11 inch to 7 ft 2 inch
- Graduation (measuring rod): 1 mm / 1/8 inch
- Power supply: Battery
- Dimensions (W x H x D): 428 x 2318 x 474 mm
- Dimensions (W x H x D): 16.9 x 91.3 x 18.7 inch
- Net weight: 5 kg / 11 lbs
Functions
- PRINT and auto-PRINT
- Wall-mounting configuration
- HOLD function for reading stability
- Calibration and automatic calibration
- Automatic switch-off
- RS232 compatible
- Wireless interface with SEND and auto-SEND
- RESET function
- Optional acoustic signals
- Backlighting
- cm/inch switch-over
- User-defined zero setting
Certification
- CE marking: CE 0123
