Zyno Medical B2 Primary IV Administration Set is a primary infusion set for continuous or intermittent delivery of IV fluids and medications with Z-800 series infusion pumps. The 105-inch set provides a sterile fluid path with an 18 mL priming volume and a calibrated drip rate of 20 drops per mL for controlled administration.
The administration set features a universal spike with a spike tip protector, a drip chamber, and flow control components to support routine infusion tasks. A roller clamp adjusts the infusion rate, while a slider clamp can be closed to stop flow when needed. A standardized male luer lock connector helps support secure connections, and an inline needleless injection site allows access for compatible devices without breaking the sterile fluid path.
Features and benefits
- Primary IV set for Z-800 series pumps
- Sterile fluid path with 18 mL priming volume
- 20 drops/mL drip rate for controlled delivery
- Universal spike with spike tip protector
- Roller clamp for flow rate adjustment
- Slider clamp to stop flow when closed
- Male luer lock connector for secure attachment
- Needleless injection port for line access
- Non-DEHP and latex-free construction
- Non-pyrogenic, single-use design
Product specifications
- Manufacturer: Zyno Medical
- Product number: B2-70070
- Quantity: Case of 50
- Priming volume: 18 mL
- Drip rate: 20 drops/mL
- Length: 105 inches
- DEHP-free: Yes
- Latex-free: Yes
- Non-pyrogenic: Yes
- Connector type: Male luer lock
- Port type: One needleless injection site
- Spike style: Universal, vented
- Application: Single-use primary
- Pump compatibility: Z-800F, Z-800W, Z-800WF
- Sterile path: Yes
